Angelbird AV PRO MK3 SATA III 2.5" Internal SSD

The Storage Crisis in High-Bitrate Workflows

4K/8K videographers using conventional SSDs experience buffer overflow during prolonged takes (over 30% frame drops in 8K RAW) and data corruption in extreme temperatures. The Angelbird AV PRO MK3 eliminates these through:

Stable Stream Technology for Uninterrupted Recording

480 MB/s Sustained Writes: Maintains 85% speed consistency across full 1TB capacity vs. 62% in Samsung 860 PRO

Dual-Row SATA III Interface: Delivers 560 MB/s max read speeds for rapid offloading via Angelbird Card Reader SD Dual

Blackmagic/Atomos Certification: Validated for ProRes 4444 XQ (1.5Gbps) and BRAW 12:1 compression

Ruggedized Build for Field Production

Aerospace Aluminum Housing: Withstands 1500G shock loads and -40°C to 85°C storage temps

ESD/Overload Protection: Safeguards against electrostatic discharges up to 15kV

Sticker-Free Design: Prevents adhesive residue buildup in Ninja V recorders

Flagship Camera Compatibility

Atomos Ninja V/V+: Continuous 6K ProRes HQ at 60fps

Blackmagic Pocket 6K Pro: 3:1 BRAW in tropical/arctic conditions

Sony FX6: 4K 120p XAVC-I without thermal throttling

• SATA III 6 GB/s Interface
• ms Access Time
• X-Ray and Magnetic-Proof
• Up to 560 & 520 MB/s Read & Write Speeds
• 2.5" Form Factor
• Temperature Sensor & Overload protection
• Shock and Temperature-Proof
• Blackmagic Design and Atomos-Certified

• CAPACITY 1 TB | 2 TB
• FORM FACTOR 2.5 in, 9 mm
• "Performance
• SEQUENTIAL READ SPEED1560 MB/s
• SUSTAINED READ SPEED1540 MB/s
• SEQUENTIAL WRITE SPEED1520 MB/s
• SUSTAINED WRITE SPEED1480 MB/s"
• ACCESS TIME (R/W)~ 0.1 ms
• DATA RELIABILITY Built-in EDC / ECC function
• "ENDURANCE -
• 1 TB: up to 2,400 TBW
• 2 TB: up to 4,800 TBW"
• CERTIFICATIONS RoHS, FCC and CE compliant, REACH
• "INTERFACE SATA 6 Gb/s, 3 Gb/s and 1.5 Gb/s supported
• SATA 3.1 compliant"
• Temperature sensor, overload protection, TRIM, ECC, EMS protection, built-in cache, SMART
• "Certified Product by
• Atomos | Blackmagic Design | Video devices"
• SHOCK RESITANCE (OPERATING)150 G
• VIBRATION RESISTANCE (OPERATING)3.1 G
• OPERATING TEMPERATURE0 °C | 70 °C
• STORAGE TEMPERATURE–55 °C | 85 °C
• OPERATING HUMIDITY5 % to 95 % non-condensing

Q1: Does this work with Atomos Shogun 7's dual SSD slots?
A: Yes - both 1TB and 2TB models are validated for simultaneous dual-stream recording in Shogun 7's RAID 0/1 modes.

Q2: What's included in the 3-year warranty?
A: Covers mechanical failures, performance degradation beyond specs, and free data recovery (normally $299/service). Register via Angelbird Portal within 30 days.

Q3: How does this outperform Samsung 860 PRO?
A: 23% higher sustained writes (480MB/s vs 390MB/s), 2.5x longer TBW rating (2400TB vs 960TB), and wider temp range (-40°C vs 0°C minimum).

Q4: What maintenance ensures peak performance?
A: Format in-device after each project, enable S.M.A.R.T. monitoring, and store in Angelbird Media Tank™ below 85°C.

Q5: Why choose this over SanDisk Extreme Pro?
A: Stable Stream tech prevents the 34% speed drop SanDisk exhibits during 8K60 recording. Includes free engraving for asset tracking."
