Head
• Load Capacity 15.4 lb (7.0 kg)
• Counter Balance System Supports 8.8 lb (4.0 kg)
• Center of Gravity 2.16" (5.49 cm)
• Quick Release/Wedge Plate 504PLONG
• Tilt Drag Continuously adjustable from 0 to max level
• Tilt Range -80° / +90°
• Leg Stages/Sections Yes
• Spring Loaded Counter Balance Yes
• Pan Range 360°
• Pan Lock Yes
Legs
• Material Aluminum
• Head Attachment Fitting 75mm bowl
• Leg Stages Two/three
• Center Brace Yes
System
• Load Capacity 15.4 lbs (7.0 kg)
• Maximum Height 66.14" (168.00 cm)
• Minimum Height 17.32" (43.99 cm)
• Closed Length 32.68" (83.01 cm)
• Leveling Bubble/Illuminated Yes/No
